德国徕卡DM IL实验室倒置生物显微镜

主要特点:Led照明
  • 产品简介
  • 技术参数
  • 可选配件

◆ LED照明倒置实验室显微镜 Leica DMIL LED

◇ 徕卡 DM IL LED 显微镜具有高性能光学元件、人体工学设计与精确的10W 发光二极管照明功能,适用于细胞与组织培养、显微操作与活细胞检查。

◇ 徕卡 DM IL LED 具备功能全面的差显技术。稳定性高、操作空间充裕、适用大型培养瓶的更长的工作距离、无需加热进行激发,以及单独的电子装置让显微镜操作更加简捷。

◇ 显微镜配备的高度可调的镜台、采用人体工学设计的镜筒允许用户调节显微镜高度、瞳距和屈光度设置。



◆ 操作舒适:

◇ 采用人体工学设计的控制元件(如焦距刻度盘、亮度控制器、聚光镜高度调节器、物镜转盘与 XY 轴镜台调节)确保用户操作更加舒适。



◆ LED、照明灯5万小时的产品寿命:

◇ 发光二极管照明装置具有极高的强度与对比度,使用寿命可达 5 万小时,可确保色温一致,并可根据差显方法自动调节亮度。

◆ 荧光发光二极管激发器:

◇ 还可提供:镜筒、加热镜台、荧光发光二极管激发器与光纤激发器等功能全面的配件,满足特殊应用要求。

◆ 案例图片:

Overview of the Leica DM IL LED:

Optics Leica HC optics (infi nity corrected)
HC objectives: 2.5x–100x
DM IL LED Fluo DM IL LED
Objective Nosepiece Four positions
Focus Coaxial coarse and fi ne adjustment, travel path 7 mm, nosepiece focusing
Transmitted-light illuminator 5 watt LED, power supply (in 100-240, out 5 V/2 A) Filter holder for TL fi lter Ø 32 mm, collector, scattering fi lter
Condenser Interchangeable condenser heads: S40/0.45: available working distance 40 mm, aperture 0.45 S80/0.30: available working distance 80 mm, aperture 0.30
Contrasting Precentered insert with four positions Insert for IMC illumination (Brightfi eld, 5x–63 x Phase Contrast)(Brightfi eld, 10x, 20x, 32x, 60x IMC)
Contrast methods Brightfi eld, Phase Contrast, Integrated Modulation Contrast
Fluorescence Fluorescence slider with three positions for fi lter cubes Manual light stop
Fluorescence illumination Fluorescence LED Leica SFL100, 50W Hg, 100W Hg, Leica EL6000 fiberoptic coupling
Stages Fixed stage, fixed heating stage, 3-plate stage, attachable mechanical stage for both fixed stages
Documentation Camera port for all Leica digital cameras and common camera models
Tubes Binocular tube 45°, interpupillary distance 55–75 mm, fi eld of view 20 mm
Tubes Trinocular phototube 45°, interpupillary distance 55–75 mm, fi eld of view 20 mm,
with camera port positioned 88 mm to the side, selectable 100% photo or 100% visual

Additional options in the Leica DM product line:

Standard binocular tube 30°, Ergo binocular tube 15°

Ergo Vario binocular tube 7.5–15°, Ergo Vario binocular tube 0–55°

Ergo Vario binocular tube 5°–32° and eyepiece extension 0–30 mm

Standard trinocular phototube 30°, Ergo Vario trinocular phototube 0°–35°
